Implement package assembly in scancode.io

[JonoYang]

This PR updates the application package scanning step in scancode.io to reflect the updates made to package scanning in scancode-toolkit. Package scanning is now a two step process, where we first detect Package data from CodebaseResources, then we iterate through all the Resources with Package data and process them using the new Package handlers from scancode-toolkit.

[tdruez]

@JonoYang thanks for splitting those PR, much easier to review and test.

1. I'm getting the following error running the scan_codebase on https://files.pythonhosted.org/packages/9b/41/e1e7d6ecc3bc76681dfdc6b373566822bc2aab96fa3eceaaed70accc28b6/Django-4.1-py3-none-any.whl

DiscoveredPackage matching query does not exist.

Traceback:
  File "scancode.io/scanpipe/pipelines/__init__.py", line 115, in execute
    step(self)
  File "scancode.io/scanpipe/pipelines/scan_codebase.py", line 93, in scan_for_application_packages
    scancode.scan_for_application_packages(self.project)
  File "scancode.io/scanpipe/pipes/scancode.py", line 332, in scan_for_application_packages
    assemble_packages(project=project)
  File "scancode.io/scanpipe/pipes/scancode.py", line 375, in assemble_packages
    for item in items:
  File "scancode.io/lib/python3.9/site-packages/packagedcode/models.py", line 941, in assemble
    cls.assign_package_to_resources(
  File "scancode.io/lib/python3.9/site-packages/packagedcode/models.py", line 1005, in assign_package_to_resources
    package_adder(package_uid, resource, codebase)
  File "scancode.io/scanpipe/pipes/scancode.py", line 344, in add_to_package
    package = project.discoveredpackages.get(package_uid=package_uid)
  File "scancode.io/lib/python3.9/site-packages/django/db/models/manager.py", line 85, in manager_method
    return getattr(self.get_queryset(), name)(*args, **kwargs)
  File "scancode.io/lib/python3.9/site-packages/django/db/models/query.py", line 496, in get
    raise self.model.DoesNotExist(

2. We should add a simple test for assemble_packages, to expose how a couple resources with package_data are assembled into a package.

[tdruez]

@JonoYang Did you have the chance to investigate the issue reported above?

[JonoYang]

@tdruez The issue is caused by DatafileHandler.assemble_from_many(), where Resources are yielded before Packages. I've set up the CodebaseResource creation logic in load_inventory and scan_codebase to create DiscoveredPackages before the CodebaseResources of a Project, such that I can associate the CodebaseResources to their DiscoveredPackages. I've modified the .assemble() methods of other DatafileHandlers to yield Packages before dependencies and resources, but I'm also looking into sorting these objects on the scancode.io side in the assemble_packages function in my PR.

This is my PR on scancode-toolkit that modifies DatafileHandler.assemble_from_many() to yield Packages before Resources and Dependencies
aboutcode-org/scancode-toolkit#3042

[JonoYang]

Sorting the items yielded by .assemble() doesn't work. We still run into the issue where we need a DiscoveredPackage to exist for a Project before we can relate a CodebaseResource to it when the .assemble() method code is determining the resources of a package.

[tdruez]

@JonoYang could you extract the changes related to #467 into it's own PR so we can get this one merge while we are sorting the assembly issues?

[JonoYang]

@tdruez

I've updated CodebaseResource.for_packages to return a list of package_uids of the DiscoveredPackages associated to the CodebaseResource. package_uid values are different every time they are generated, so in tests where we compare package_uid values, we normalize them using purl_with_fake_uuid. I was wondering what was the best way to normalize a package_uid from the CSV output test (https://github.com/nexB/scancode.io/blob/implement-package-assembly/scanpipe/tests/test_pipes.py#L132)

[JonoYang]

I've updated CodebaseResource.for_packages to return a list of package_uids of the DiscoveredPackages associated to the CodebaseResource. package_uid values are different every time they are generated, so in tests where we compare package_uid values, we normalize them using purl_with_fake_uuid. I was wondering what was the best way to normalize a package_uid from the CSV output test (https://github.com/nexB/scancode.io/blob/implement-package-assembly/scanpipe/tests/test_pipes.py#L132)

Looking at it again, I now realize there is no need to normalize the package_uids in the for_packages field in the CSV tests because the Package data is set in code and in the fixtures and we will always get the same package_uid returned. In scancode-toolkit, we need to normalize the package_uids because scancode generates a unique package_uid on each test run.

[tdruez]

@JonoYang I'm not sure your latest changes were intended to fix #485 (comment) but I'm still getting the same issue with the latest code.

[JonoYang]

@JonoYang I'm not sure your latest changes were intended to fix #485 (comment) but I'm still getting the same issue with the latest code.

The PR with this fix has been merged into scancode-toolkit and should be available in the next version and I'll bump the scancode version in scio when it comes out. (aboutcode-org/scancode-toolkit#3042)

[tdruez]

@JonoYang I've merged the latest main branch including the ScanCode-toolkit v31.0.1 version.

1. The issue "DiscoveredPackage matching query does not exist." from Implement package assembly in scancode.io #485 (comment) appears to be fixed.

I'm seeing an extra resource associated to the second package using the main branch that I do not see in this current branch:

• main


• implement-package-assembly


Also, shouldn't we only detect 1 package here?

---

2. I'm still getting this issue in the assemble_packages() with this branch running the docker pipeline on docker://python:3.8-slim-buster:

CodebaseResource matching query does not exist.

Traceback:
  File "/app/scanpipe/pipelines/__init__.py", line 115, in execute
    step(self)
  File "/app/scanpipe/pipelines/root_filesystems.py", line 118, in scan_for_application_packages
    scancode.scan_for_application_packages(self.project)
  File "/app/scanpipe/pipes/scancode.py", line 332, in scan_for_application_packages
    assemble_packages(project=project)
  File "/app/scanpipe/pipes/scancode.py", line 375, in assemble_packages
    for item in items:
  File "/usr/local/lib/python3.9/site-packages/packagedcode/models.py", line 949, in assemble
    cls.assign_package_to_resources(
  File "/usr/local/lib/python3.9/site-packages/packagedcode/pypi.py", line 319, in assign_package_to_resources
    site_packages = resource.parent(codebase).parent(codebase).parent(codebase)
  File "/app/scanpipe/models.py", line 1632, in parent
    return parent_path and self.project.codebaseresources.get(path=parent_path)
  File "/usr/local/lib/python3.9/site-packages/django/db/models/manager.py", line 85, in manager_method
    return getattr(self.get_queryset(), name)(*args, **kwargs)
  File "/usr/local/lib/python3.9/site-packages/django/db/models/query.py", line 650, in get
    raise self.model.DoesNotExist(

[JonoYang]

@tdruez

CodebaseResource matching query does not exist.

Traceback:
File "/app/scanpipe/pipelines/init.py", line 115, in execute
step(self)
File "/app/scanpipe/pipelines/root_filesystems.py", line 118, in scan_for_application_packages
scancode.scan_for_application_packages(self.project)
File "/app/scanpipe/pipes/scancode.py", line 332, in scan_for_application_packages
assemble_packages(project=project)
File "/app/scanpipe/pipes/scancode.py", line 375, in assemble_packages
for item in items:
File "/usr/local/lib/python3.9/site-packages/packagedcode/models.py", line 949, in assemble
cls.assign_package_to_resources(
File "/usr/local/lib/python3.9/site-packages/packagedcode/pypi.py", line 319, in assign_package_to_resources
site_packages = resource.parent(codebase).parent(codebase).parent(codebase)
File "/app/scanpipe/models.py", line 1632, in parent
return parent_path and self.project.codebaseresources.get(path=parent_path)
File "/usr/local/lib/python3.9/site-packages/django/db/models/manager.py", line 85, in manager_method
return getattr(self.get_queryset(), name)(*args, **kwargs)
File "/usr/local/lib/python3.9/site-packages/django/db/models/query.py", line 650, in get
raise self.model.DoesNotExist(

This error is happening because we do not create the directory Resources when we create Resources from a docker image. The fix for this is to set with_dir=True as an argument into layer.get_resources() (https://github.com/nexB/scancode.io/blob/main/scanpipe/pipes/docker.py#L176)

After fixing that issue, the pipeline failed from a syntax error in PythonInstalledWheelMetadataFile.assign_package_to_resources(). I've created a PR for it (aboutcode-org/scancode-toolkit#3059)

After fixing the syntax error in PythonInstalledWheelMetadataFile.assign_package_to_resources(), I'm able to run the docker pipeline without errors.

[JonoYang]

I'm seeing an extra resource associated to the second package using the main branch that I do not see in this current branch:

main
Screenshot 2022-08-18 at 15 15 14

implement-package-assembly
Screenshot 2022-08-18 at 15 16 03

Also, shouldn't we only detect 1 package here?

With the current logic we have in packagedcode, there should be two Packages detected: 1 from the wheel itself and 1 from the extracted METADATA file. We would have 1 detected package if the scan_codebase pipeline did not have an extraction step.

INFO Project test8 assemble_packages:
INFO   Processing: Django-4.1-py3-none-any.whl
INFO   Package data: pkg:pypi/[email protected]
INFO   Selected package handler: PypiWheelHandler
INFO     Processing item: Package(type='pypi', namespace=None, name='Django', version='4.1', datasource_id='pypi_wheel')
INFO     Processing item: Dependency(purl='pkg:pypi/asgiref', extracted_requirement='asgiref<4,>=3.5.2', scope='install')
INFO     Processing item: Dependency(purl='pkg:pypi/sqlparse', extracted_requirement='sqlparse>=0.2.2', scope='install')
INFO     Processing item: Dependency(purl='pkg:pypi/backports-zoneinfo', extracted_requirement='backports.zoneinfo; python_version < "3.9"', scope='install')
INFO     Processing item: Dependency(purl='pkg:pypi/tzdata', extracted_requirement='tzdata; sys_platform == "win32"', scope='install')
INFO     Processing item: Dependency(purl='pkg:pypi/argon2-cffi', extracted_requirement='argon2-cffi>=19.1.0; extra == "argon2"', scope='argon2')
INFO     Processing item: Dependency(purl='pkg:pypi/bcrypt', extracted_requirement='bcrypt; extra == "bcrypt"', scope='bcrypt')
INFO     Processing item: Django-4.1-py3-none-any.whl
INFO   Processing: Django-4.1-py3-none-any.whl-extract/Django-4.1.dist-info/METADATA
INFO   Package data: pkg:pypi/[email protected]
INFO   Selected package handler: PythonInstalledWheelMetadataFile
INFO     Processing item: Package(type='pypi', namespace=None, name='Django', version='4.1', datasource_id='pypi_wheel_metadata')
PythonInstalledWheelMetadataFile: assign_packages_to_resources: Django-4.1-py3-none-any.whl-extract/Django-4.1.dist-info/METADATA
INFO     Processing item: Dependency(purl='pkg:pypi/asgiref', extracted_requirement='asgiref<4,>=3.5.2', scope='install')
INFO     Processing item: Dependency(purl='pkg:pypi/sqlparse', extracted_requirement='sqlparse>=0.2.2', scope='install')
INFO     Processing item: Dependency(purl='pkg:pypi/backports-zoneinfo', extracted_requirement='backports.zoneinfo; python_version < "3.9"', scope='install')
INFO     Processing item: Dependency(purl='pkg:pypi/tzdata', extracted_requirement='tzdata; sys_platform == "win32"', scope='install')
INFO     Processing item: Dependency(purl='pkg:pypi/argon2-cffi', extracted_requirement='argon2-cffi>=19.1.0; extra == "argon2"', scope='argon2')
INFO     Processing item: Dependency(purl='pkg:pypi/bcrypt', extracted_requirement='bcrypt; extra == "bcrypt"', scope='bcrypt')
INFO     Processing item: Django-4.1-py3-none-any.whl-extract/Django-4.1.dist-info/METADATA

I guess we could be a bit more clever by update the package assembly code upstream to not process METADATA or other Package manifest files for an extracted wheel.

Regarding the extra resource associated with the second package, I may have overlooked assigning a resource to a package somewhere. I will have to check in depth.

This is due to PythonInstalledWheelMetadataFile expecting the Resource Django-4.1-py3-none-any.whl-extract/Django-4.1.dist-info/METADATA to be in a site-packages directory when it is not. (https://github.com/nexB/scancode-toolkit/blob/develop/src/packagedcode/pypi.py#L320)

[tdruez]

@JonoYang with the latest toolkit 31.0.2 the DoesNotExist is now properly fixed.
I've encountered a new ProjectError reported aboutcode-org/scancode-toolkit#3067 but unrelated to this PR.
Merging!
